Elevator Parts for THYSSENKRUPP

Elevator Parts for THYSSENKRUPP | Supplier & Technical Components

NONA Elevator supplies OEM-equivalent and aftermarket replacement parts for THYSSENKRUPP (TK Elevator) systems. We support independent maintenance contractors, modernization specialists, and distributors with field-tested electrical boards, inverters, traction machines, door operators, and mechanical safety components.
All electronics undergo full-load test bench verification prior to dispatch to eliminate on-site protocol mismatch and field failure.

First 12 3 4 Last 1/4

Elevator Parts for Repair, Replacement & Modernization

Emergency Repair Supply

Rapid-dispatch stocks for critical downtime items, including main control boards, drive units, door sensors, and brake coils.

Scheduled Maintenance Items

High-wear components, including traction sheaves, synthetic ropes, guide shoes, oil seals, and roller guides.

Complete Modernization Kits

Integrated package solutions featuring controller, inverter, door operator, and COP/LOP signal fixtures pre-configured for TK shaft dimensions.

Elevator Parts by Brand Compatibility

Control System / Model Series	Supported Hardware & PCB Components	Typical Applications
TAC 32 / TAC 50 / TAC 2	CPU boards, I/O drivers, power supply modules, encoder interface cards	Commercial mid-rise & high-rise elevators
MC2 / CPI / CPIC Series	Inverter motherboards (AS.L03/F), drive boards (AS.L01/J), PG cards (AS.L06/D)	Variable-frequency geared & gearless installations
ISIS / Synergy / Synergy3	Flat traction belting, compact gearless machine parts, door operator drives	Machine-room-less (MRL) residential systems
Evolution / Tugela / Velino	Escalator main boards, step chains, comb plates, boundary rollers	Public transit & commercial escalators

Elevator Components by Type

1. Control Boards & Inverters
Main Control Boards: Pre-flashed with stable firmware protocols (such as IOC-3B Ver2.2 G02 and LCB-II platforms).
Frequency Inverters & Drive Units: CPIC-I, CPIC-II, CPIC-III, CPIC-V, and CPIK series frequency converters (rated from 13A to 65A output).
Interface & Signal Boards: Hall call indicator boards (TLHIB-1A), cabin communication modules, and matrix display panels (MA9 S/E).

2. Door Systems & Actuators
Door Inverters & Drives: DMIC I C and DMIC I F door control units with plug-and-play harness connections.
Door Operators & Hangers: VVVF door operators, synchronous belt drives, door clutch assemblies, and interlock switches.
Safety Protection: Multi-beam infrared light curtains (174 or 192 beams) with built-in power supply boxes.

3. Mechanical & Safety Equipment
Traction Sheaves & Gearless Motors: Replacement sheaves for PMS280, PMS300, and PMS320 traction machines with hardened groove profiles (RC 52-58).
Safety Gears & Overspeed Governors: Bi-directional progressive safety gears compliant with EN 81-20/50 tripping speeds.
Oil Buffers & Guides: Hydraulic polyurethane buffers, synthetic guide shoes, and oil collectors.

ThyssenKrupp Elevator Inverter Motherboard AS.L03/F

Specifications, MOQ & Lead Time

Parameter / Category	Standard Specification / Condition
Minimum Order Quantity (MOQ)	1 piece for electronics, inverters, and boards; 5-10 pieces for mechanical wear items.
Standard Lead Time	Electronics in stock: 24-48 hours dispatch. Custom sheaves or cables: 7-10 working days.
Operating Temperature	-10 deg C to +60 deg C (Control units & drive electronics).
Voltage Tolerance	AC 380V +/- 15%, 50/60 Hz (Standard 3-phase power input).
Certification Standards	CE, ISO9001, EN 81-20/50 safety compliance.
Warranty Period	12 months full replacement warranty on control electronics and drive units.

ThyssenKrupp elevator CPIC series PCB board AS.L03F inverter motherboard with AS.L01J driver board

Elevator Modernization Solutions

Complete panel-and-harness modernization modules allow contractors to replace obsolete TK controllers while retaining structural guide rails, car frames, and counterweight assemblies.
Retained Structure:
Counterweight frames and filler blocks
Elevator car frame and safety gear assembly
T-section car and counterweight guide rails

Replaced Modernization Hardware:
Integrated Control Cabinet (Pre-wired Terminal Blocks)
VVVF Door Operator & Mechanical Clutch Assembly
CAN-bus Signal System & Car Operating Panel (COP/LOP)
Encoder & Shaft Positioning Sensors

Modernization Technical Specifications:
Control Interface: CAN-bus serial communication reducing shaft cable core counts by up to 60%.
Drive Efficiency: Integrated VVVF closed-loop control supporting both induction and permanent magnet synchronous motors (PMSM).
Compliance: Built to satisfy EN 81-20/50 and ASME A17.1 code standards.

Compatibility & Model Matching

To ensure 100% first-time installation compatibility, verify the following parameters before placing an order:

PCB Orders

Provide the main board part number, revision code, sticker barcode, and elevator floor or speed configuration.

Inverter & Drive Replacement

Match the motor power output (kW), input voltage (3-phase 380V/440V), current rating (A), and encoder protocol (Absolute EnDat or Incremental TTL).

Traction Sheaves

Confirm pitch diameter (mm), rope diameter (mm), groove quantity, and shaft center bore dimensions.

Quality Control & Testing

Full-Load Simulator Testing

Inverters and main boards run on motor-loaded test towers to verify current stability under peak duty cycles.

Signal Protocol Validation

I/O channels, encoder inputs, and CAN-bus communication loops are tested against OEM signal standards.

Solder Joint Optical Inspection

Automated Optical Inspection (AOI) for all repaired or re-manufactured PCB surface-mount assemblies.

Hardness & Dynamic Balance

Traction sheaves undergo dynamic balancing (G2.5 rating) and surface hardness testing (HB 190-240 for cast iron sheaves).

Packaging, Delivery & After-Sales

ESD Anti-Static Packaging: Electronic boards and drives are sealed in anti-static shielding bags with moisture-absorbent desiccants and custom EPE foam inserts.

Export Wood Craters: Heavy items (traction machines, sheaves, hydraulic buffers) are packed in IPPC-stamped, fumigation-free plywood crates.

Global Freight Logistics: Express air freight (DHL, FedEx, UPS) for emergency repairs (3-5 day delivery worldwide); sea freight for bulk modernization orders.

Technical Support: Remote diagnostic support by experienced elevator technicians for parameter setup, error code clearing, and wiring verification.

productcate-1-1

Certificate

fAQ

Q: How do I verify if a control board or inverter is compatible with my specific TK elevator system?

A: Check the part number on the PCB barcode label, the software version sticker (such as IOC-3B Ver2.2 G02), and the inverter model code (such as CPIC-III-34B.A). Send us photos of the component nameplate and existing wiring layout; our engineering team will cross-reference the drawing database to confirm exact pin-to-pin compatibility before dispatch.

Q: Are your replacement electronics new, reconditioned, or OEM?

A: We supply both original brand-new components and high-grade OEM-compatible replacement units. All reconditioned or surplus modules undergo full-load dynamic bench testing and component-level inspection. Product condition is explicitly stated in every official quotation.

Q: What if the elevator main board displays an error code or loses parameter settings after installation?

A: Our technical support team provides step-by-step guidance for parameter initialization and handheld programmer navigation. If a parameter matching issue occurs due to custom job-site configurations, we assist in adjusting terminal parameter tables or dispatching replacement chips with correct firmware configurations.

Q: Can you supply complete modernization panels to replace obsolete ThyssenKrupp controllers?

A: Yes. We supply pre-wired controller cabinets with integrated VVVF drives designed to interface with existing shaft limit switches, door operators, and car structures. Every panel includes labeled terminal blocks and a customized electrical schematic diagram tailored to your project.

Q: What is the warranty coverage for TK elevator spare parts?

A: All electrical boards, inverters, and drive units carry a 12-month replacement warranty starting from the date of bill of lading. If a component fails under normal operating conditions within this period, we ship a replacement unit upon receiving the technical diagnostic log.

Q: What are the standard shipping options for urgent emergency repair orders?

A: For emergency breakdown situations, stock items are dispatched via express air courier (DHL, FedEx, UPS) within 24 hours. International express delivery typically arrives at European and North American job sites within 3 to 5 business days.
